Dictionary of iPhone Terminology

Dictionary of iPhone Terminology

Posted March 17, 2008 at 11:12pm by iClarified · 90070 views
Spanish
Here is a dictionary of iPhone terms to help you understand the words commonly used in the iPhone community. We will be adding terms regularly. If you would like to see a term added please request it in the comments!


Activation
When you first purchase your iPhone all you can do is call 911 until you activate with AT&T (or similar). If you are using an official Apple carrier carrier then you can activate through iTunes; otherwise you will have to perform a hack to activate your iPhone. Once activated it becomes an iPod touch with camera and bluetooth at which point you will want to proceed to jailbreak and possibly unlock it for use on other carriers.

Baseband
The Baseband controls the interaction between the Phone part of the iPhone and the operating system. Whenever the iPhone needs to talk to cell towers-- whether for voice or data-- it works through the Baseband. The Baseband is responsible for making sure the sim-card is valid and for getting Signal. When you unlock your iPhone the baseband is modified to allow communication to other wireless carriers. The latest baseband version is 04.04.05_G and it corresponds to the 1.1.4 firmware.


Bootloader
There are at least two bootloaders in the iPhone. One is the ARM Core Bootloader and deals with the Operating System, the other is the Baseband Bootloader. Bootloaders make sure that when the iPhone boots it is doing things in the right order, and getting everything done. Currently the iPhone has shipped with two different Baseband Bootloaders (3.9 and 4.6). The 3.9BL allowed us to load a hacked baseband which matches the firmware version. Apple changed this feature in the 4.6 BL and made it require a baseband of a newer firmware version. This is why the Dev Team has released a 3.9 fakeblank BL which allows you to load a hacked baseband matching your firmware version.

DFU Mode
DFU means Device Firmware Update. If a restore using Recovery Mode doesn't work you will want to use DFU Mode as a last resort. When placing your iPhone into DFU Mode it does not load the OS before attempting the restore. Hold the Sleep/Wake and Home buttons for 10 seconds. Just before you would normally see the Apple logo, release the Sleep/Wake button and keep hold the Home button until an iTunes detects an iPhone in recovery mode. NOTE**: This is really tricky to get the timing right it will take a few attempts. If you are in DFU Mode your screen will be black with nothing displayed.

Firmware
The firmware version you have installed on the iPhone is similar to the version of the operating system on your computer. Newer firmware versions usually add new features, fix bugs, and improve stability. iPhones first shipped with 1.0.x firmware. iPhones now are shipping with 1.1.4 and version 1.2 (2.0 Beta) is available to select developers.

Installer.app
Installer.app is a UIKit based package manager for the iPhone. It works by downloading packages over WiFi (wireless networking) or EDGE. It supports installing, updating and uninstalling applications from multiple sources. You will use Installer.app to install a majority of your iPhone applications.

Jailbreak
The process of gaining access to the iPhone's root filesystem, allowing third-party applications to run on the device. In general once you jailbreak you will have Installer.app, Cydia, or Icy on your SpringBoard. You can use these utilities to install most every application you would need on your iPhone.

OOB or OTB
Used to refer to the firmware version your iPhone came with "Out of the Box". ie. If you have a 1.1.2 OTB iPhone that means your iPhone came with the 1.1.2 firmware preinstalled.

Recovery Mode
If you want to do a clean restore you can put your iPhone into recovery mode to do so. Hold the Sleep/Wake and Home buttons until the iPhone reboots. Once you see the Apple logo, release the Sleep/Wake button and keep hold the Home button until an iTunes logo and the usb cable appear on screen. You can then use iTunes to restore your firmware.

Secpack
A Secpack is similar to a password for the Bootloader. When passed to the bootloader, it authorizes write access to the Baseband.

SDK
SDK is short for Software Development Kit and it's basically a library of software that helps you develop applications and utilities. Apple has just released the iPhone SDK which is the set of tools needed to create applications that run on the iPhone.

Unlock
The process of Unlocking allows your iPhone to use any GSM sim card. Currently Apple has limited the use of the iPhone to a select few wireless carriers. The iPhone must be unlocked before you can use any carrier of your choice.


Dictionary of iPhone Terminology
Add Comment
Would you like to be notified when someone replies or adds a new comment?
Yes (All Threads)
Yes (This Thread Only)
No
iClarified Icon
Notifications
Would you like to be notified when we post a new Apple news article or tutorial?
Yes
No
You must login or register to add a comment...
iSohrab
iSohrab - November 14, 2010 at 11:46am
Hi Plz add HSHS
Connor
Connor - July 28, 2008 at 10:16pm
What does to "neuter" a bootloader mean?
k
k - April 15, 2008 at 12:35am
wanted this for a long time
brainlara
brainlara - March 27, 2008 at 2:44pm
That's really very handy..like a cheat sheet. Great job.
sandric3004
sandric3004 - March 22, 2008 at 4:22am
maybe add "virginize"
Meshary
Meshary - March 18, 2008 at 8:09am
Could you please explain Cydia, and is it like installer?
srinivas
srinivas - March 18, 2008 at 7:59am
Wanted this for long time, tq
Adam
Adam - March 18, 2008 at 7:50am
I get a lot of questions about the difference in OOB and OTB as well, if you could add those.
Danny
Danny - March 18, 2008 at 5:53am
Hi... could you please explain what is Seczone, Secpack, Nor, NCK token... It would be really great if u provide some info on this..
Sean S
Sean S - March 18, 2008 at 5:07am
Could you please add what SDK stands for.
Chris Wanja
Chris Wanja - March 18, 2008 at 12:02am
Might want to add to "Recover Mode" the fact that you have to have a power source connected to it unless you are using a GUI application
samradley
samradley - March 17, 2008 at 11:44pm
does "unlocking" iPhone means I can swap out GSM SIM cards from multiple carrier and all of those work? or will i have to re-activate/unlock iPhone every time i swap out GSM SIM card?
