Forward a Port Using Your Airport Extreme

Posted April 3, 2008 at 1:04am by iClarified
Portuguese (Brazil)
These are instructions on how to use port forwarding and forward a port on your Airport Extreme Base Station.

Step One
Launch the AirPort Utility from your Applications:Utilities folder.
Forward a Port Using Your Airport Extreme

Step Two
Select your Base Station from the list on the left and then click the Manual Setup button.
Forward a Port Using Your Airport Extreme


Step Three
Click to select the Advanced tab from the top of the Manual Setup window.
Forward a Port Using Your Airport Extreme

Step Four
Click to select Port Mapping from the top of the Advanced Settings.
Forward a Port Using Your Airport Extreme

Step Five
Click the + button to add a new port forward. The plus button can be found under the list of existing port forwards.
Forward a Port Using Your Airport Extreme

Step Six
Enter the settings for the port forward rule. The public ports are the ports that external computers will use to connect. The Private IP Address is the IP Address of the computer in your network that you would like the public ports to forward to. The private ports are the ports on your local computer that you would like the public ports to point to. ie so an external computer could think its connecting to port 80 on your computer but the router would resolve it to a different port of your choice.
Forward a Port Using Your Airport Extreme

Once you have inputed the correct settings for your port forward rule, click the Continue button.

Step Seven
Enter a description for your port forward rule.
Forward a Port Using Your Airport Extreme

If you like you could enable Bonjour to broadcast the rule globally but we will leave this alone for now.

Click the Done button to save your new rule.

Step Eight
Now press the Update button at the bottom right hand corner to update your router with the new port forwarding rule. Please note this will reboot your AirPort Extreme Base Station!
Forward a Port Using Your Airport Extreme
