Alleged iPhone 14 Pro Max CAD Renders and Dimensions Reveal Smaller Bezels, Shorter Earpiece, More

Alleged iPhone 14 Pro Max CAD Renders and Dimensions Reveal Smaller Bezels, Shorter Earpiece, More

Posted April 5, 2022 at 3:27pm by iClarified · 3860 views
New CAD renders and dimensions for the upcoming iPhone 14 Pro Max have allegedly been leaked. The renders were shared by ShrimpApplePro on Twitter and reveal new information about the widely rumored device.

Here are the images of the cad file and full measurements of iPhone 14 Pro Max that I obtained. I will share more details about it in the coming newsletter.

The iPhone 14 Pro Max will purportedly be 78.53mm wide (including side button), 160.71mm tall, and 12.16mm thick. It will feature bezels that are 1.95mm thick compared to 2.42mm thick on the iPhone 13 Pro Max. That means its bezels are about 19.4% thinner.

The earpiece is said to be 0.57mm in height, compared to 1.52mm on the iPhone 13 Pro Max. That's around 62.5% shorter.

In regards to the pill+hole cutouts, the right punch hole is said to be 5.59mm in diameter. The left pill cutout is the same diameter with the distance between the center points of the arcs being 7.15mm. Finally, the distance from the cutouts to the top of the screen is said to be 2.29mm.

The rear camera bump is purportedly 4.18mm in height. The rear camera diameter with metal ring is 13.85mm and without is 8.05mm. The rear flash diameter is said to be 6.9mm and the LiDAR sensor diameter is purportedly 6.5mm.

Lastly, the renders show that the iPhone 14 Pro Max will not have a USB-C port.

Take a look below!
